Koupit AX97-10151 s BYCHPS
Koupit se zárukou
AX97-10151
- Part Number:
- AX97-10151
- Výrobce:
- Triad Magnetics
- Popis:
- FIXED IND 150UH 220MA 3.08 OHM
- Stav volného vedení / RoHS:
- Bez olova / V souladu RoHS
- dostupné množství:
- 15871 Pieces
- Datový list:
- AX97-10151.pdf
Úvod
BYCHIPS je distribuční odrůda pro AX97-10151, máme zásoby pro okamžitou přepravu a také k dispozici pro dlouhodobé zásobování. Zašlete nám svůj plán nákupu AX97-10151 e-mailem vám poskytneme nejlepší cenu podle svého plánu.
Specifikace
| Typ: | Wirewound |
|---|---|
| Tolerance: | ±20% |
| Dodavatel zařízení Package: | - |
| Velikost / Rozměry: | 0.287" L x 0.188" W (7.30mm x 4.78mm) |
| stínění: | Unshielded |
| Série: | AX97 |
| hodnocení: | - |
| Q @ Freq: | - |
| Obal: | Bulk |
| Paket / krabice: | Nonstandard |
| Provozní teplota: | - |
| Typ montáže: | Surface Mount |
| Materiál - jádro: | Ferrite |
| Výrobní standardní doba výroby: | 16 Weeks |
| Výrobní číslo výrobce: | AX97-10151 |
| indukčnost: | 150µH |
| Výška - Sedící (Max): | 0.127" (3.23mm) |
| Frekvence - Test: | 100kHz |
| Frekvence - Self Resonant: | - |
| Rozšířený popis: | 150µH Unshielded Wirewound Inductor 220mA 3.08 Ohm Max Nonstandard |
| Popis: | FIXED IND 150UH 220MA 3.08 OHM |
| DC Resistance (DCR): | 3.08 Ohm Max |
| Jmenovitá hodnota proudu: | 220mA |
| Proud - Saturace: | - |
| Email: | [email protected] |
