Koupit MMIX1T132N50P3 s BYCHPS
Koupit se zárukou
MMIX1T132N50P3
- Part Number:
- MMIX1T132N50P3
- Výrobce:
- IXYS Corporation
- Popis:
- SMPD HIPERFETS & MOSFETS
- Stav volného vedení / RoHS:
- Bez olova / V souladu RoHS
- dostupné množství:
- 15911 Pieces
- Datový list:
- 1.MMIX1T132N50P3.pdf2.MMIX1T132N50P3.pdf
Úvod
BYCHIPS je distribuční odrůda pro MMIX1T132N50P3, máme zásoby pro okamžitou přepravu a také k dispozici pro dlouhodobé zásobování. Zašlete nám svůj plán nákupu MMIX1T132N50P3 e-mailem vám poskytneme nejlepší cenu podle svého plánu.
Specifikace
| Vgs (th) (max) 'Id: | 5V @ 8mA |
|---|---|
| Vgs (Max): | ±30V |
| Technika: | MOSFET (Metal Oxide) |
| Dodavatel zařízení Package: | Polar3™ |
| Série: | Polar™ |
| RDS On (Max) @ Id, Vgs: | 43 mOhm @ 66A, 10V |
| Ztráta energie (Max): | 520W (Tc) |
| Obal: | Tube |
| Paket / krabice: | 24-PowerSMD, 22 Leads |
| Provozní teplota: | -55°C ~ 150°C (TJ) |
| Typ montáže: | Surface Mount |
| Úroveň citlivosti na vlhkost (MSL): | 1 (Unlimited) |
| Výrobní standardní doba výroby: | 10 Weeks |
| Výrobní číslo výrobce: | MMIX1T132N50P3 |
| Vstupní kapacita (Ciss) (Max) @ Vds: | 18600pF @ 25V |
| Nabíjení brány (Qg) (Max) @ Vgs: | 267nC @ 10V |
| Typ FET: | N-Channel |
| FET Feature: | - |
| Rozšířený popis: | N-Channel 500V 63A (Tc) 520W (Tc) Surface Mount Polar3™ |
| Napětí měniče (max. Zap. RDS, min. Zap. Zap.): | 10V |
| Drain na zdroj napětí (Vdss): | 500V |
| Popis: | SMPD HIPERFETS & MOSFETS |
| Proud - kontinuální odtok (Id) @ 25 ° C: | 63A (Tc) |
| Email: | [email protected] |
