Koupit IXTP270N04T4 s BYCHPS
Koupit se zárukou
IXTP270N04T4
- Part Number:
- IXTP270N04T4
- Výrobce:
- IXYS Corporation
- Popis:
- MOSFET N-CH 40V 270A
- Stav volného vedení / RoHS:
- Bez olova / V souladu RoHS
- dostupné množství:
- 16452 Pieces
- Datový list:
- IXTP270N04T4.pdf
Úvod
BYCHIPS je distribuční odrůda pro IXTP270N04T4, máme zásoby pro okamžitou přepravu a také k dispozici pro dlouhodobé zásobování. Zašlete nám svůj plán nákupu IXTP270N04T4 e-mailem vám poskytneme nejlepší cenu podle svého plánu.
Specifikace
| Vgs (th) (max) 'Id: | 4V @ 250µA |
|---|---|
| Vgs (Max): | ±15V |
| Technika: | MOSFET (Metal Oxide) |
| Dodavatel zařízení Package: | TO-220AB |
| Série: | TrenchT4™ |
| RDS On (Max) @ Id, Vgs: | 2.4 mOhm @ 50A, 10V |
| Ztráta energie (Max): | 375W (Tc) |
| Obal: | Tube |
| Paket / krabice: | TO-220-3 |
| Provozní teplota: | -55°C ~ 175°C (TJ) |
| Typ montáže: | Through Hole |
| Úroveň citlivosti na vlhkost (MSL): | 1 (Unlimited) |
| Výrobní standardní doba výroby: | 8 Weeks |
| Výrobní číslo výrobce: | IXTP270N04T4 |
| Vstupní kapacita (Ciss) (Max) @ Vds: | 9140pF @ 25V |
| Nabíjení brány (Qg) (Max) @ Vgs: | 182nC @ 10V |
| Typ FET: | N-Channel |
| FET Feature: | - |
| Rozšířený popis: | N-Channel 40V 270A (Tc) 375W (Tc) Through Hole TO-220AB |
| Napětí měniče (max. Zap. RDS, min. Zap. Zap.): | 10V |
| Drain na zdroj napětí (Vdss): | 40V |
| Popis: | MOSFET N-CH 40V 270A |
| Proud - kontinuální odtok (Id) @ 25 ° C: | 270A (Tc) |
| Email: | [email protected] |
