Koupit LNX2G123MSEJ s BYCHPS
Koupit se zárukou
LNX2G123MSEJ
- Part Number:
- LNX2G123MSEJ
- Výrobce:
- Nichicon
- Popis:
- CAP ALUM 12000UF 20% 400V SCREW
- Stav volného vedení / RoHS:
- Bez olova / V souladu RoHS
- dostupné množství:
- 17563 Pieces
Úvod
BYCHIPS je distribuční odrůda pro LNX2G123MSEJ, máme zásoby pro okamžitou přepravu a také k dispozici pro dlouhodobé zásobování. Zašlete nám svůj plán nákupu LNX2G123MSEJ e-mailem vám poskytneme nejlepší cenu podle svého plánu.
Specifikace
| napìtí: | 400V |
|---|---|
| Tolerance: | ±20% |
| Povrchová montáž Land Velikost: | - |
| Velikost / Rozměry: | 3.543" Dia (90.00mm) |
| Série: | LNX |
| Ripple Current: | 25.5A @ 120Hz |
| Polarizace: | Polar |
| Obal: | Bulk |
| Paket / krabice: | Radial, Can - Screw Terminals |
| Ostatní jména: | 493-9145 LNX2G123MSEJ-ND |
| Provozní teplota: | -25°C ~ 85°C |
| Typ montáže: | Chassis Mount |
| Úroveň citlivosti na vlhkost (MSL): | 1 (Unlimited) |
| Výrobní standardní doba výroby: | 21 Weeks |
| Výrobní číslo výrobce: | LNX2G123MSEJ |
| Životnost @ Temp.: | 20000 Hrs @ 85°C |
| Rozestup vývodù: | 1.252" (31.80mm) |
| Impedance: | - |
| Výška - Sedící (Max): | 7.598" (193.00mm) |
| Rozšířený popis: | 12000µF 400V Aluminum Capacitors Radial, Can - Screw Terminals 20000 Hrs @ 85°C |
| ESR (Equivalent Resistance Series): | - |
| Popis: | CAP ALUM 12000UF 20% 400V SCREW |
| kapacitní: | 12000µF |
| Aplikace: | General Purpose |
| Email: | [email protected] |
