Koupit DLW5BTM102TQ2K s BYCHPS
Koupit se zárukou
DLW5BTM102TQ2K
- Part Number:
- DLW5BTM102TQ2K
- Výrobce:
- Murata Electronics
- Popis:
- CMC 2.5A 2LN 1 KOHM SMD
- Stav volného vedení / RoHS:
- Bez olova / V souladu RoHS
- dostupné množství:
- 12537 Pieces
Úvod
BYCHIPS je distribuční odrůda pro DLW5BTM102TQ2K, máme zásoby pro okamžitou přepravu a také k dispozici pro dlouhodobé zásobování. Zašlete nám svůj plán nákupu DLW5BTM102TQ2K e-mailem vám poskytneme nejlepší cenu podle svého plánu.
Specifikace
| Napìtí - DC: | 50V |
|---|---|
| Napìtí - AC: | - |
| Velikost / Rozměry: | 0.197" Dia x 0.197" W (5.00mm x 5.00mm) |
| Série: | DLW5B |
| hodnocení: | - |
| Obal: | Original-Reel® |
| Paket / krabice: | Horizontal, 6 PC Pad |
| Ostatní jména: | 490-9291-6 |
| Provozní teplota: | -40°C ~ 105°C |
| Počet řádků: | 2 |
| Typ montáže: | Surface Mount |
| Úroveň citlivosti na vlhkost (MSL): | 1 (Unlimited) |
| Výrobní číslo výrobce: | DLW5BTM102TQ2K |
| Indukčnost @ Frekvence: | - |
| Impedance @ Frekvence: | 1 kOhm @ 100MHz |
| Výška (Max): | 0.098" (2.50mm) |
| Typ filtru: | Power, Signal Line |
| Funkce: | - |
| Rozšířený popis: | 2 Line Common Mode Choke Surface Mount 1 kOhm @ 100MHz 2.5A DCR 34 mOhm |
| Popis: | CMC 2.5A 2LN 1 KOHM SMD |
| DC odpor (DCR) (Max): | 34 mOhm |
| Karta Tloušťka (mm): | 2.5A |
| schválení: | - |
| Email: | [email protected] |
Související díly pro DLW5BTM102TQ2K
| Obraz | Part Number | Výrobci | Popis | Pohled |
|---|---|---|---|---|
 |
DLW5BTM102TQ2L | Murata Electronics North America | CMC 2.5A 2 100OHM SMD | Dotaz |
|
DLW5BTM102SQ2L | Murata Electronics North America | CMC 2A 2LN 1 KOHM SMD | Dotaz |
|
DLW5BTM101TQ2L | Murata Electronics North America | CMC 6A 2LN 100 OHM SMD | Dotaz |
|
DLW5BTM101SQ2L | Murata Electronics North America | CMC 6A 2LN 100 OHM SMD | Dotaz |
|
DLW5BTM142SQ2L | Murata Electronics North America | CMC 1.5A 2LN 1.4 KOHM SMD | Dotaz |
|
DLW5BTM501TQ2L | Murata Electronics North America | CMC 4A 2LN 500 OHM SMD | Dotaz |
|
DLW5BTM142TQ2L | Murata Electronics North America | CMC 2A 2LN 1.4 KOHM SMD | Dotaz |
|
DLW5BTM251TQ2L | Murata Electronics North America | CMC 5A 2LN 250 OHM SMD | Dotaz |
|
DLW5BTM251SQ2L | Murata Electronics North America | CMC 5A 2LN 250 OHM SMD | Dotaz |
